Single Head Single Needle Comforter Quilting Machine Lock Stitch
Automatic pattern track search function, automatic power-off memory function,
Equipment detection function and stop automatically when the thread is broken.
Whatsapp: + 86 183 2211 2838
E-mail: rita@huimei-machine.com
The best quilting machine for small spaces--single needle comforter quilting machine
The single needle comforter quilting machine lock stitch HMH01 is specially designed for comforter manufacturers with limited production space. It has features that other quilting machines do not have as following:
| Type | HM-H012224 | HM-H012426 | HM-H012628 | HM-H012830 |
| Quilting size | 2.2*2.4 m | 2.4*2.6 m | 2.6*2.8 m | 2.8*3.0 m |
| Quilting head | single head, single needle , doule-line lock stitch , big rotary hook | |||
| Quilting thickness | max 1200 gsm | |||
| Quilting speed | 2000-2200 RPM | 2000-2200 RPM | 2000-2200 RPM | 2000-2200 RPM |
| Machine size | 2.8*2.8*1.2 m | 3.0*3.2*1.2 m | 3.2*3.4*1.2 m | 3.4*3.6*1.2 m |
| Weight | 650 kg | 700 kg | 750 kg | 800 kg |
Unique structure of single needle comforter quilting machine lock stitch
1) Head-moving movement mode, small footprint, only 3/5 of other quilting machines, suitable for limited space work
2) High precision: Unlike traditional quilting machines, when quilting, the material is not move, and the movement of the machine head makes the quilting precision higher
3) The large-stroke machine head improves the stability when quilting thick materials
4) The overall structure of the machine is optimized, using precision splines and steel-core polyurethane synchronous belts
Humanized automatic operating system of single needle comforter quilting machine lock stitch:
1) Automatic shutdown when thread breaks, and when shutting down, the quilting needle automatically stops at a high position
2) Automatic pattern track search function, which can be used to advance and retract needles on the screen
3) Automatic power-off memory function. Don't worry about interrupting the quilting process due to power outages caused by power or line problems. After restarting the machine, just press the switch button to quilt normally
4) Adjustable frame: Provides convenient frame boundary setting and modification functions
5) Linear bearings are used at the connection between the machine head and the chassis, making it easier to run
6) Equipment detection function. It can quickly detect various external information of the machine, making it easy to quickly find faults.
Service of single needle comforter quilting machine lock stitch
1) Professional guidance to select the model and size as needed
2) Conventional packaging or optional wooden box packaging
3) Small order quantity 1 set suitable for trial orders
4) Various payment methods available: T/T, WESTERN UNION, PAYPAL, ALIPAY etc.
5) Pre-shipment inspection support
6) If you encounter any problems during use, you can contact after-sales 7*24 hours
WhatsApp: +8618322112838
