Automatic single needle quilting machine computerized
Two movement modes: head movement and frame movement single needle quilting machine
2000 RPM-3500 RPM quilting speed is optional
Quilting thickness max 1200 gsm
Whatsapp: + 86 183 22112838
E-mail: rita@huimei-machine.com
Single needle quilting machine overview:
As a manufacturer with 20 years of experience in quilting machine production, Huimei has been committed to providing the most suitable single needle quilting machines for all kinds of customers. With the continuous advancement of technology, we now have two main types of quilting machines. One is a small-footprint, economical head move single needle quilting machine (HM-H01 and HM-H02), and the other is a high-configuration, fast quilting frame move single needle quilting machine (HM-H03, HM-H04 and HM-H05).
| Product Model | HM-H01 | HM-H02 | HM-H03 | HM-H04 | HM-H05 |
| Motor | Head frequency conversion + stepper motor | Head servo + stepper motor | Head servo + stepper motor | Full servo motor | Full servo motor |
| Machine head | ordinary machine head | ordinary machine head | Direct drive head | Direct drive head | Direct drive head, automatic lifting |
| Frame | single beam, small and thin | single beam, small and thin | Single beam, small and thin, automatic thread trimming and automatic oiling | single beam, automatic thread trimming and automatic oiling | double beam, automatic thread trimming and automatic oiling |
| Operation screen | Keyboard screen | Keyboard screen | Touch screen | Touch screen | Touch screen |
| Quilting speed | 2000-2200 RPM | 2000-2200 RPM | 2200-2500 RPM | 2800-3000 RPM | 3000-3500 RPM |
| Quilting thickness | max 4 cm | max 4 cm | max 4 cm | max 5 cm | max 8 cm |
| Output in 8.5 hour | 100 pcs | 150 pcs | 150-200 pcs | 250-300 pcs | 350 pcs |
| Feature | small footprint and low price | small footprint and low price | High stability | High stability | Good stability, high precision, no displacement |
Single needle quilting machine features:
1: Various models available: 4 machine size for each models, from 2.2*2.4m quilting size to 3.0*3.2 m quilting size;
2: Adjustable quilt frame: you can quilt any size smaller than the selected quilt frame;
3: Real-time display of quilting status and operation instructions to facilitate workers' operation;
4: Automatically stops when the thread is broken or the thread is used up;
5:The frame move single needle quilting machine uses a direct-drive machine head, automatic thread trimming, automatic oiling, and a variety of optional patterns;
6: The head move single needle quilting machine has a small footprint, just can occupy 3/5 of other quilting machines.
......
Feel free to contact us for more further information!
Service of single needle quilting machine:
1: Patient pre-sales service to help you choose the right model and size;
2: MOQ: 1set;
3: bulk package (platic cover) or wooden box package (optional);
4: Strict quality inspection before shipment;
5: 7*24 hours online guide
